American & Japanese terminal blocks FB601-02-16P-8.4
American & Japanese terminal blocks FB601-02-16P-8.4

 Pitch:8.4mm,Electrical:UL,Rated Voltage:/,Rated Current:/,colour:green ;

 In order to meet the requirements of different application,With and without plastic cover are optional ;

 The products are designed according to IEC60998 and UL1059 international standard and also certified by UL。


 Pitch:8.4mm

 Electrical:UL

 Rated Voltage:/

 Rated Current:/

 Wire Diameter Range(AWG/mm²)20-14/0.5-2.5

 Operating Temperature Range:-40℃~+105℃

 Withstand Voltage:  /

 Strip Length:-6-7mm


Datasheet
Material and Finish
HosuingPA66 UL94V-0
Electric conductorCopper Alloy,Tin-plated
Fastening piece Screw/SpringSteel,Zinc-plated
Fastening piece Cage/NutSteel
Electric Characteristics                ULIEC
Rated Voltage/630V
Rated Current/15A
Withstand Voltage/
Impulse Withstand Voltage6KV
Connection Characteristics
Wire Diameter Range(AWG/mm²)20~14/0.5~2.5
Strip Length6-7mm
TorqueM3,0.5N.m
Operating Temperature Range-40℃~+105℃

Order Number
Package Unit
MOQ

Product Weight

(Excluding Package)
