American & Japanese terminal blocks FB601-03-7.0
American & Japanese terminal blocks FB601-03-7.0

 Pitch:7.0mm,Electrical:UL,Rated Voltage:300V,Rated Current:15A,colour:grey ;

 In order to meet the requirements of different application,With and without plastic cover are optional ;

 The products are designed according to IEC60998 and UL1059 international standard and also certified by UL。


 Pitch:7.0mm

 Electrical:UL

 Rated Voltage:300V

 Rated Current:15A

 Wire Diameter Range(AWG/mm²)22-14/0.75-2.5

 Operating Temperature Range:-40℃~+105℃

 Withstand Voltage:  AC1600V/1min

 Strip Length:5-7mm


Datasheet
Material and Finish
HosuingPA66 UL94V-0
Electric conductorCopper Alloy,Tin-plated
Fastening piece Screw/SpringSteel,Zinc-plated
Fastening piece Cage/NutSteel,Zinc-plated
Electric Characteristics                ULIEC
Rated Voltage300V400V
Rated Current15A15A
Withstand VoltageAC1600V/1Min
Impulse Withstand Voltage4KV
Connection Characteristics
Wire Diameter Range(AWG/mm²)22~14/0.75~2.5
Strip Length5-7mm
TorqueM3,0.5N.m
Operating Temperature Range-40℃~+105℃

Order Number
Package Unit
MOQ

Product Weight

(Excluding Package)
