Screw terminal blocks AF103-01-11P-15.0
Screw terminal blocks AF103-01-11P-15.0

 Pitch:15.0mm,Electrical:UL,Rated Voltage:300V,Rated Current:30A,colour:black ;

 combined with single-layer, double-layer and three-layer designs, to diversify the selectivity of applications ;

 The products are designed according to IEC60998 and UL1059 international standard and also certified by UL and TUV。


 Pitch:15.0mm

 Electrical:UL

 Rated Voltage:300V

 Rated Current:30A

 Wire Diameter Range(AWG/mm²)24~10/0.34~4

 Operating Temperature Range:-40℃~+105℃

 Withstand Voltage:  AC2500V/1min

 Strip Length:8-10mm


Datasheet
Material and Finish
HosuingPA66 ,UL94V-0
Electric conductorCopper Alloy, Tin-plated
Fastening piece Screw/SpringSteel,Zinc-plated
Fastening piece Cage/NutCopper Alloy,,Zinc-plated
Electric Characteristics                ULIEC
Rated Voltage300V630V
Rated Current30A32A
Withstand VoltageAC2500V/1min
Impulse Withstand Voltage6KV
Connection Characteristics
Wire Diameter Range(AWG/mm²)24~10/0.34~4
Strip Length8-10mm
TorqueM3.5,1.0N.m
Operating Temperature Range-40℃~+105℃



Order Number
Package Unit
MOQ

Product Weight

(Excluding Package)
