Screw terminal blocks F130-5.0
Screw terminal blocks F130-5.0

• Pitch:5.0mm,Electrical:UL,Rated Voltage:300V,Rated Current:20A,colour:green ;

• combined with single-layer, double-layer and three-layer designs, to diversify the selectivity of applications ;

• The products are designed according to IEC60998 and UL1059 international standard and also certified by UL and TUV。


→ Pitch:5.0mm

→ Electrical:UL

→ Rated Voltage:300V

→ Rated Current:20A

→ Wire Diameter Range(AWG/mm²):24~12/0.2~4.0

→ Operating Temperature Range:-40℃~+105℃

→ Withstand Voltage:  AC2000V/1min

→ Strip Length:6-7mm


Datasheet
Material and Finish
HosuingPA66 ,UL94V-0
Electric conductorBrass, Tin-plated
Fastening piece Screw/SpringSteel,Zinc-plated
Fastening piece Cage/NutBrass,Nickel-plated
Electric Characteristics                ULIEC
Rated Voltage300V320V
Rated Current20A24A
Withstand VoltageAC2000V/1min
Impulse Withstand Voltage4KV
Connection Characteristics
Wire Diameter Range(AWG/mm²)24~12/0.2~4.0
Strip Length6~7mm
Torque
M3,0.5N.m
Operating Temperature Range-40℃~+105℃



Order Number
Package Unit
MOQ

Product Weight

(Excluding Package)
